Octa Energy

Octa Smart Wall

Octa Smart Wall is a single-port charging station for electric vehicles designed for commercial use. Its characteristics and capabilities allow you to install this device in public places – in the car parks of cinemas, gyms, shops, shopping malls, etc.

OCPP protocol support

The commercial version of Octa Smart Wall communicates with the server using the OCPP 1.6 protocol (JSON) and can be connected to any mobile application. You receive information about the charging session in real time.

Made with our own technology

Octa UCP technology allows you to combine various electronic modules to create charging stations of any configuration. The main module in the Octa Smart Wall is the UCP ComboChannel. It fully controls the charging process and prevents dangerous situations. The Smart Wall series also has its own UCP SuperMain communication module, which implements OCPP 1.6 (JSON) for communication with the operator’s server.

Protected from weather conditions

Octa Wall can withstand any weather, does not require additional protection from sun, rain, wind or snow and continues to perform at its optimum level all year round. It is IP54 rated for protection against moisture and dust.

Combines durability and style

Octa Wall is a futuristic design in a robust metal case. The front of the station is made of impact-resistant plastic. There is an LED indication of the charging station status. The electronics are housed in a double casing, which provides perfect protection for their performance in extreme conditions.

Compatible with any electric vehicle

Octa charging stations are compatible with any brand of electric vehicle. Our experts will help you choose the right connector for your electric vehicle.

Reliable and safe

Octa Wall is equipped with all possible protections and interlocks in case of mains faults, namely: RCDs, differential current leakage protection, grounding quality check, protection against atmospheric electricity, no voltage in the connector in standby mode, overcurrent protection, overvoltage protection, short circuit protection, contactor sticking control, temperature control.

User access control

All Smart Wall stations are equipped with an RFID reader, which allows you to activate the charging process using access cards.

Specifications

Types of possible connectors: Type 1 / Type 2 / GBT

Power consumption: Depends on the selected connector (up to 22 kW)

Indication of the charging station status: Present

Material: Metal housing

Protection class of the case: IP54

RFID access control: Present

OCPP protocol support: Present (OCPP 1.6)

Warranty: 12 months

Manufacturer: Ukraine (Octa Energy)
